JUNG Visu Pro software

JUNG Visu Pro Software for installation on your own Windows PC

you can choose between the English and the German version. Each installation will run in demo mode for 20 days or 400 starts. For an unrestricted use the software must be activated via a myJUNG account. License purchase exclusively via the JUNG online shop

Intended use

20320 1S IPS R, 2131 USBS REG, 2131 USBS), not included Product characteristics

Process connections

• Visualisation and operation of KNX systems via devices with HTML5 browser or app tablet, laptop, PC, etc.
• Support of KNX IP Secure and KNX Data Secure
• Connection to KNX bus via interfaces (ref.-no. IPR 300 SREG, IPS 300 SREG,
• Access from max. 20 different clients possible (with Windows 10)
• Integration of Amazon Alexa voice control via myJUNG account
• Integration of Google Home voice control via myJUNG account
• Integration of Samsung SmartThings via myJUNG account
• Secure remote access via myJUNG account (JVP-L necessary)
• Secure remote sharing with further myJUNG accounts
• Reading and controlling Modbus data via Modbus TCP
• Access to IP cameras via RTSP
• Control of IP cameras via ONVIF (profile S)
• Multilingual visualisation can be created
• Visualisation switchable between day/night
• Update and upgrade compatible
• KNX editor / KNX editor 2.0
• instalight editor
• Device editor
• vitaLED editor
• XPL editor
• Modbus editor
• Process model
• Visualisation editor
• Work sheet generator
• Calendar
• JUNG Visu Pro Starter

Technical requirements Hardware

Operating systems

KNX editor The Falcon driver of the KNX Association is used for the KNX bus. The KNX connection Data import from ETS

• Windows 10 + 11 requires a suitable version of the Falcon driver and the respective interfaces.
• Use of project export of ETS
• The ETS keyring is required for a KNX Secure connection
